5L/h Spray Dryer up to 250C with SS316 Chambers - MSK-USP-5L
HomeStore

5L/h Spray Dryer up to 250C with SS316 Chambers - MSK-USP-5L

5L/h Spray Dryer up to 250C with SS316 Chambers - MSK-USP-5L

$192,498.60

Original: $549,996.00

-65%
5L/h Spray Dryer up to 250C with SS316 Chambers - MSK-USP-5L—

$549,996.00

$192,498.60

The Story

MSK-USP-5L is a pilot or production spray dryer that generates fine particles by evaporating the atomized liquid spray and that has been collected through the cyclone separating process.
The maiximum Evaporation Capacity is 5 liter per hour.
It is suitable for synthesizing heat-sensitive materials for a broad range of applications such as Pharmaceuticals, Nanotechnology, Catalysts, Fuel cells, and Batteries.

SPECIFICATIONS
System Features
  • A dual-channel spray nozzle with an anti-clogging function prevents the nozzle from being clogged during the spray process
  • High Sample Collection Efficiency: 95%
  • The user-friendly control panel enables easy adjustment of temperature, airflow & pressure, pumping speed, and anti-clogging interval
  • The maximum Evaporation Capacity is 5 liters per hour
  • Digital control panel
  • Built-in PID temperature controller for accurate Inlet/outlet air temperature control
  • Solvent feeding via a peristaltic pump, the rate is adjustable
Input Voltage & Power
  • 380VAC, 50/60 Hz Three Phases
  • 18 KW
Flow Chart
Spray Nozzle (Atomizer)
  • Compress gas-assist spray nozzle disperses spray liquid into fine droplets which are subsequently dried in the 800 mm diameter chamber
  • The dual-channel design allows the mixing and spraying of two kinds of solutions at the same time
  • Anti-clogging nozzle, auto anti-clogging interval adjustable
  • Co-current downward spray
  • Atomized particle sizes range from 1 - 120 um
  • Spray Nozzle Size is 0.7mm Dia.
  • Optional: Temperature-controlled nozzle up to 450ºC is available upon request at the extra cost.
Cyclon Material Collector
  • Material collection efficiency can be as high as 95%.
  • Collect Capacity: 10 L
Temperature Control
  • Inlet air: 30 300
  • Outlet air: 30 140
  • Max. working Temperature: 250
  • PID temperature controller with ±2 accuracy
Drying Time
  • 1~1.5S
Drying Air
  • One oil-less air compressor is included
  • 120 L/min
  • Pressure: 0.5 - 1 MPa
Peristaltic Pump
  • The solvent is fed by the peristaltic pump
  • Feeding rate adjustable: 302200ml/h
Evaporation Capability
  • Max. 5 L/hr
Certification
  • CE Certified
  • NRTL or CSA certification is available upon request



5L/h Spray Dryer up to 250C with SS316 Chambers - MSK-USP-5L - Image 2

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Description

MSK-USP-5L is a pilot or production spray dryer that generates fine particles by evaporating the atomized liquid spray and that has been collected through the cyclone separating process.
The maiximum Evaporation Capacity is 5 liter per hour.
It is suitable for synthesizing heat-sensitive materials for a broad range of applications such as Pharmaceuticals, Nanotechnology, Catalysts, Fuel cells, and Batteries.

SPECIFICATIONS
System Features
  • A dual-channel spray nozzle with an anti-clogging function prevents the nozzle from being clogged during the spray process
  • High Sample Collection Efficiency: 95%
  • The user-friendly control panel enables easy adjustment of temperature, airflow & pressure, pumping speed, and anti-clogging interval
  • The maximum Evaporation Capacity is 5 liters per hour
  • Digital control panel
  • Built-in PID temperature controller for accurate Inlet/outlet air temperature control
  • Solvent feeding via a peristaltic pump, the rate is adjustable
Input Voltage & Power
  • 380VAC, 50/60 Hz Three Phases
  • 18 KW
Flow Chart
Spray Nozzle (Atomizer)
  • Compress gas-assist spray nozzle disperses spray liquid into fine droplets which are subsequently dried in the 800 mm diameter chamber
  • The dual-channel design allows the mixing and spraying of two kinds of solutions at the same time
  • Anti-clogging nozzle, auto anti-clogging interval adjustable
  • Co-current downward spray
  • Atomized particle sizes range from 1 - 120 um
  • Spray Nozzle Size is 0.7mm Dia.
  • Optional: Temperature-controlled nozzle up to 450ºC is available upon request at the extra cost.
Cyclon Material Collector
  • Material collection efficiency can be as high as 95%.
  • Collect Capacity: 10 L
Temperature Control
  • Inlet air: 30 300
  • Outlet air: 30 140
  • Max. working Temperature: 250
  • PID temperature controller with ±2 accuracy
Drying Time
  • 1~1.5S
Drying Air
  • One oil-less air compressor is included
  • 120 L/min
  • Pressure: 0.5 - 1 MPa
Peristaltic Pump
  • The solvent is fed by the peristaltic pump
  • Feeding rate adjustable: 302200ml/h
Evaporation Capability
  • Max. 5 L/hr
Certification
  • CE Certified
  • NRTL or CSA certification is available upon request
